Derale Hyper-Cool Remote Engine Oil Cooler Kit 25 Row -8AN 15660

Derale 15660 With its own air supply, this new remote cooler can literally be mounted almost anywhere, making it a popular addition for performance cars, hot rods, muscle cars and trucks. Featuring our top of the line aluminum 25-row Stacked Plate cooler coupled with a Tornado fan and aluminum shroud, this universal kit comes with a complete installation kit to install easily on most vehicle engines. Also included is an 180'F in-line thermostat for activating the electric fan. The Hyper-Cool Engine Oil Cooler kit is perfect for applications where space is limited but engine cooling is a necessity.

Specifications:

Cooler style: Stacked Plate.

Inlet size: -10AN / 7/8"-14 o-ring female x -8AN male.

Fan size: 8".

CFM: 500.

Amp draw: 4.8.

Width: 13".

Height: 10".

Depth: 5-5/8".

Inlet dim: 10".

Mounting: 7-1/2" x 9".

Sandwich adapter inlet size: 3/8" NPT.

Hose size: 1/2".

Hose length: 10'.

46,000 BTU's Per Hour.

Cooler is rated at 250psi working pressure and 300psi burst strength.

Features:

Mounts anywhere space permits.

Electric fan supplies optimum airflow.

Dramatically extends engine and transmission life.

High efficiency Stacked Plate cooler.

Clear anodized aluminum shroud.

500 CFM reversible Tornado electric fan.

-8AN inlet size.

46,000 BTU's Per Hour.

Engine cooler kit includes fan mounted cooler, universal thermostatic sandwich adapter, 13/16-16", 3/4-16", 18mm, 20mm, & 22mm sleeve nuts, two -8AN fittings, four 1/2" hose barb fittings, 180'F In-line thermostat,10 ft. OEM spec hose & hardware.
