Derale 9" Straight Blade Reversible 475Cfm Electric Fan with Thermostat 16309
Derale 16309 9" Dyno Cool Straight Blade Reversible 475Cfm Electric Fan with Adjustable Thermostat.
This reliable 9" straight blade electric fan moves 475 CFM at 0 static pressure, drawing only 6.4 amps. Included in kit: fan, mounting kit, mechanical fan controller with adjustable turn on temp between 32�F-240�F with turn off set at 10�F below turn on. Uses a capillary tube radiator hose probe design.
Features:
Ultra low profile design.
Straight fan blades.
475 CFM.
Reversible design - can be used as a pusher or puller.
Complete fan control kit includes 180� thermostat with both thread-in water jacket probe and push-in radiator probe, relay wire harness, all mounting hardware and wire connections.
Specifications:
Fan size: 9".
CFM: 475.
Amp draw: 5.5.
Width: 9-9/16".
Height: 10 7/16".
Depth: 1-1/4".
Overall depth: 2-1/4".
Mounting: 4-7/16".
Airflow: Puller (reversible).
